Engineers Inspect Ultraviolet Spectrograph

Engineers inspect Europa Clipper's ultraviolet spectrograph in a cleanroom at NASA's Jet Propulsion Laboratory in Southern California
Source: NASA/JPL-Caltech
Published: March 3, 2022

Engineers inspect Europa Clipper's ultraviolet spectrograph (called Europa-UVS) in a cleanroom at NASA's Jet Propulsion Laboratory in Southern California, following the delivery of the instrument from Southwest Research Institute (SwRI).
