Ultraviolet Spectrograph Delivered to JPL

Source: NASA/JPL-Caltech
Published: March 3, 2022

Europa Clipper's ultraviolet spectrograph (called Europa-UVS), developed by Southwest Research Institute (SwRI), is delivered to NASA's Jet Propulsion Laboratory in Southern California.
